Product Features

A split structure can be adopted, with the refrigeration unit and the box placed separately
The top of the box is perforated for easy lifting of the motor
Box bottom has 4 support holes sealed with molded silicone plugs to prevent frost & water overflow
The central axis adopts a special sealing device to avoid frosting at low temperatures

Product Parameter

Model		Studio Size? (DWH)mm	Dimension（DWH）mm
LRHS-274C-LJ		650×650×650	Temperature box size about 852×850×1300

temperature range	-55℃～85℃
Temperature uniformity	≤2.0℃ (at no load)
Temperature fluctuation	±1.0℃ (at no load)
temperature deviation	±1.0℃ (at no load)
Temperature rise and fall rate	85℃～-55℃ (with a load of 80KG stainless steel throughout the non-linear average of 2.0℃/min)
Outer case material	Adopting high quality (t=1.2mm) A3 steel plate processed by CNC machine, and the surface of the shell is sprayed with plastic.
Inner box material	Made of high quality stainless steel (SUS304)
Insulation material	Rigid polyurethane foam + fiberglass
Controller	Adopting Japan “UEC” brand temperature meter, 7-inch high-definition true-color LCD touch screen display
refrigeration system	France “Taikang” hermetic air-cooled compressor refrigeration method
rotation scheme	Box on a rotary table, horizontal rotary motion, speed does not exceed 70 rpm
terminal	Refrigeration two-channel rotary joints
security protection		Compressor low pressure/overload/high pressure alarm, fan motor overload, overall equipment timing, short circuit, phase loss, over temperature, leakage and other protection
Supply Voltage		AC380V±10% 50Hz
Power		16.0kW

Solution

New energy vehicles

Automotive vehicle reliability test chamber is widely used in the automotive industry vehicle environment and automotive parts and components enterprises, measurement and testing organizations and scientific research units, etc., the chamber has a high-temperature test, low-temperature test, constant-temperature and constant-humidity test and other comprehensive test conditions, used to measure the performance of the automobile in different temperatures and humidity under the environmental conditions of the performance test, including the cold start, tailpipe emissions, demisting, defrosting test, and so on.

Aerospace

Aerospace vehicles experience extreme temperatures, pressures, vibrations and other environmental conditions during flight. In order to ensure that they can work safely and reliably, material components need to be tested for reliability.

Semiconductor chip

Through the use of LINPIN environmental test equipment, we can comprehensively evaluate the performance of chips under various extreme environmental conditions to ensure that they maintain efficient and stable operation in practical applications. If there is a specific product or test demand, you can choose the appropriate test chamber program according to the actual situation of the customer.

Photovoltaic energy storage

With the rapid development of renewable energy sources, photovoltaic energy storage systems are playing an increasingly important role in the global energy market. These systems need to maintain efficient operation under various extreme environmental conditions. Therefore, environmental testing of PV energy storage systems has become critical. Environmental test chambers provide an ideal platform for simulating various environmental conditions to ensure the performance and durability of PV energy storage systems.

Consumer Electronics

LINPIN can provide the consumer electronics industry, including electronic components, assemblies, and all kinds of finished products, such as: cell phones, tablets, computers, all kinds of wearable devices and other related industry product testing solutions.

Rotary table test chamber
