Product Features

A split structure can be adopted, with the refrigeration unit and the box placed separately
The top of the box is perforated for easy lifting of the motor
Box bottom has 4 support holes sealed with molded silicone plugs to prevent frost & water overflow
The central axis adopts a special sealing device to avoid frosting at low temperatures

Product Parameter

Model	Studio Size? (DWH)mm	Dimension（DWH）mm
LRHS-1584B-SN	1200×1100×1200	2150×1340×2750

irradiated area	1000mm×1000mm
radiation intensity	≥1000W/m2(55W/m2~1200W/m2 program classification)
Irradiance deviation	≤±10%(at a distance of not less than 0.76 m from the radiation lamp)
Power value of irradiation intensity	55W/m2 ~1120W/m2（adjustable)
Distance from anticondensation filter system to sample	450～1150mm(Distance adjustable)
temperature range	-40℃～+100℃(without light)、-20℃～+100℃(with light)
Temperature uniformity	≤2.0℃ ?(at no load)
Temperature fluctuation	≤±0.5℃(without light) 、≤±1℃(with light)
heating rate	-40℃～+100℃，average rate 3℃/min
cooling rate	+100℃～-40℃，average rate 3℃/min
Dew point temperature range	+5°C to 87°C (without light), +5°C to +74°C (with light);
Outer case material	Double-sided galvanized high-quality cold-rolled steel plate, surface electrostatic spray treatment, plate thickness t=1.5mm
Inner box material	Stainless steel plate (SUS304-CP 2B ground), plate thickness t=1.0mm
Insulation material	120mm rigid polyurethane foam insulation layer
Controller	Taiwan “Wyland” temperature and humidity controller (7.0 inches, high-definition true color “TFT” LCD touch screen)
refrigeration system	France “Taikang” hermetic air-cooled compressor refrigeration method
temperature sensor	High Accuracy Pt100 Platinum Resistance Temperature Sensors
Humidity Sensor	Highly accurate Vaisala capacitive humidity sensors from Finland
lighting system	German original imported “OSRAM” short arc xenon lamps
radiation meter	Sunlight intensity meter imported from Japan
security protection		Compressor low pressure/overload/high pressure alarm, hydrogen/oxygen/soot concentration alarm, fan overload, system abnormality alarm, emergency stop switch, water shortage, short-circuit, phase shortage, over-temperature and other protections
Supply Voltage		AC380V±10% 50Hz
Power		24.5kW

Solution

New energy vehicles

Automotive vehicle reliability test chamber is widely used in the automotive industry vehicle environment and automotive parts and components enterprises, measurement and testing organizations and scientific research units, etc., the chamber has a high-temperature test, low-temperature test, constant-temperature and constant-humidity test and other comprehensive test conditions, used to measure the performance of the automobile in different temperatures and humidity under the environmental conditions of the performance test, including the cold start, tailpipe emissions, demisting, defrosting test, and so on.

Aerospace

Aerospace vehicles experience extreme temperatures, pressures, vibrations and other environmental conditions during flight. In order to ensure that they can work safely and reliably, material components need to be tested for reliability.

Semiconductor chip

Through the use of LINPIN environmental test equipment, we can comprehensively evaluate the performance of chips under various extreme environmental conditions to ensure that they maintain efficient and stable operation in practical applications. If there is a specific product or test demand, you can choose the appropriate test chamber program according to the actual situation of the customer.

Photovoltaic energy storage

With the rapid development of renewable energy sources, photovoltaic energy storage systems are playing an increasingly important role in the global energy market. These systems need to maintain efficient operation under various extreme environmental conditions. Therefore, environmental testing of PV energy storage systems has become critical. Environmental test chambers provide an ideal platform for simulating various environmental conditions to ensure the performance and durability of PV energy storage systems.

Consumer Electronics

LINPIN can provide the consumer electronics industry, including electronic components, assemblies, and all kinds of finished products, such as: cell phones, tablets, computers, all kinds of wearable devices and other related industry product testing solutions.

Sunlight simulation test chamber
