4000-662-888| Model | Studio Size? (D*W*H)mm | Dimension（D*W*H）mm | |
| LRHS-8M-LG | 2000×2000×2000 | Subject to contractual three-view | |
| LRHS-15M-LG | 2500×3000×2000 | ||
| LRHS-30M-LG | 3000×5000×2000 | ||
| LRHS-60M-LG | 5000×6000×2000 | ||
| temperature range | RT+10℃～85℃/RT+10℃～150℃/ RT+10℃～200℃ | ||||||
| Temperature uniformity | ≤2℃ (at no load) | ||||||
| Temperature fluctuation | ±0.5℃ (at no load) | ||||||
| Time Setting Range | 1～60000M | ||||||
| heating rate | RT+10℃～85℃≤30min | ||||||
| Outer case material | High-quality library board, CNC finishing | ||||||
| Inner box material | Imported high-grade stainless steel SUS304 | ||||||
| Insulation material | Rigid polyurethane foam + fiberglass | ||||||
| Temperature Controller | Imported “UEC” brand temperature and humidity meter | ||||||
| temperature sensor | PT100 platinum resistance temperature measurement body | ||||||
| overtemperature protector | Korea RAINBOW | ||||||
| Miniature Circuit Breaker | Schneider France | ||||||
| standard configuration | Emergency stop switch, three-color indicator light | ||||||
| security protection | Over-temperature, fan motor overheating, overall equipment phase failure/reverse phase Leakage protection, overall equipment timing, overload and short circuit protection |
||||||
| Supply Voltage | AC380V±10% 50Hz | ||||||
| Power consumption | 15.0kW | 20.5kW | 28.0kW | 35.0kW | |||
| operating environment | 5℃～＋28℃ ≤85% RH | ||||||
| Note: 1、the test data are used in the ambient temperature of 25 ℃ and well ventilated conditions measured 2、Can be customized according to the specific requirements of the user non-standard constant temperature aging room etc 3、This technical information, subject to change without notice |
|||||||
