4000-662-888A split structure can be adopted, with the refrigeration unit and the box placed separately
The top of the box is perforated for easy lifting of the motor
Box bottom has 4 support holes sealed with molded silicone plugs to prevent frost & water overflow
The central axis adopts a special sealing device to avoid frosting at low temperatures
Model | Studio Size? (D*W*H)mm | Dimension(D*W*H)mm | |
LRHS-96M3 | 12000×4000×2000 | roughly 12200×4200×2600 |
Temperature range | RT+5℃~60℃ | ||||||
Temperature fluctuation | ≤±0.5℃(unladen) | ||||||
Temperature uniformity | ≤2.0℃(unladen) | ||||||
Temperature deviation | ±2.0℃ | ||||||
Heating rate | 0.7~1.0℃/min | ||||||
Other | Equipped with fresh air system | ||||||
Outer box material | High-quality library board | ||||||
Inner box material | Imported high-grade stainless steel SUS304 | ||||||
Insulation | Environmental protection rock wool board | ||||||
Viewing window | Conductive insulating glass | ||||||
Temperature Controller | Imported “UMC” brand temperature and humidity meter | ||||||
Temperature sensor | PT100 Platinum resistance thermometer | ||||||
Heating mode | Electrically heated Nitro alloy | ||||||
Safety | Fan, motor, pump overcurrent overload protection, limit, undervoltage, short circuit, phase loss, over temperature, leakage protection | ||||||
Supply Voltage | AC380V±10% 50Hz | ||||||
Power | 52KW | ||||||
Note: 1、 the above data are in the use of ambient temperature of 25 ℃ and well ventilated conditions measured 2、Can be customized according to the user’s specific test requirements of ice-covered test chamber, ice-covered test chamber, etc. 3、This technical information, subject to change without notice |
